Industrial PU Aluminum Center Castor
Industrial PU Aliminium Center Castor
Product Code
INDPUALICAST
From
£13.50
£11.25
Please contact us on 01384 424232
to discuss discounts for large quantities of 10 or more
to discuss discounts for large quantities of 10 or more
Suitable for applications with medium/heavy-duty loads, also with mechanical handling, with speed up to 6 km/h. The excellent rolling resistance allows an easy handling of heavy loads even with wheels of small diameter. Examples of recommended applications: trolleys for indoor industrial handling, AGV trolleys, containers, electrical pallet trucks, tilt trucks.
wheel-Ø |
fork type |
castor type |
mounting |
mounting size |
platethickness / forkthickness |
housing surface |
wheelcenter |
centercolor |
tread |
shore A |
tread color |
temperaturerange |
bearing |
threadguard |
threadguardcolor |
Test/normal |
width of Tread (mm) |
width of hub (mm) |
wheel center hole (mm) |
screw size (mm) |
size of plate (mm) |
plate hole centres (mm) |
plate hole (mm) |
offset(mm) |
overal height (mm) |
swivel radius (mm) |
load capacity (kg) |
100 | swivel | Premium | plate | 80X60 mm/52 | 4.00/3.00 | zinc blue | Aluminum | Alu | Polyurethan | 95 | brown | - 20 to + 60°C | double ball bearing | without | without | EN standard | 40 | 40 | 12 | 8 | 105x80 | 80/77x60 | 9 | 40 | 128 | 250 | |
125 | swivel | Premium | plate | 80X60 mm/52 | 4.00/3.00 | zinc blue | Aluminum | Alu | Polyurethan | 95 | brown | - 20 to + 60°C | double ball bearing | without | without | EN standard | 40 | 50 | 15 | 10 | 105x80 | 80/77x60 | 9 | 40 | 155 | 300 | |
100 | fixed | Premium | plate | 80X60 mm/52 | 3.00/3.00 | zinc blue | Aluminum | Alu | Polyurethan | 95 | brown | - 20 to + 60°C | double ball bearing | without | without | EN standard | 40 | 40 | 12 | 8 | 105x80 | 80/77x60 | 9 | 128 | 250 | ||
125 | fixed | Premium | plate | 80X60 mm/52 | 3.00/3.00 | zinc blue | Aluminum | Alu | Polyurethan | 95 | brown | - 20 to + 60°C | double ball bearing | without | without | EN standard | 40 | 50 | 15 | 10 | 105x80 | 80/77x60 | 9 | 155 | 300 | ||
100 | swivel with total brake | Premium | plate | 80X60 mm/52 | 4.00/3.00 | zinc blue | Aluminum | Alu | Polyurethan | 95 | brown | - 20 to + 60°C | double ball bearing | without | without | EN standard | 40 | 40 | 12 | 8 | 105x80 | 80/77x60 | 9 | 40 | 128 | 127 | 250 |
100 | swivel with total brake | Premium | plate | 80X60 mm/52 | 4.00/3.00 | zinc blue | Aluminum | Alu | Polyurethan | 95 | brown | - 20 to + 60°C | double ball bearing | without | without | EN standard | 40 | 50 | 15 | 10 | 105x80 | 80/77x60 | 9 | 45 | 155 | 127 | 300 |
